Shelly Plus 2PM
156,70 RON
129,50 RON
(fara TVA)
Cum te putem ajuta?
Specifications
| Physical | |
|---|---|
| Size (HxWxD): | 37x42x16 ±0.5 mm / 1.46x1.65x0.63 ±0.02 in |
| Weight: | |
| Mounting: | Wall console |
| Screw terminals max torque: | 0.4 Nm / 3.5 lbin |
| Conductor cross section: | 0.5 to 1.5 mm² / 20 to 16 AWG |
| Conductor stripped length: | 5 to 6 mm / 0.20 to 0.24 in |
| Shell material: | Plastic |
| Color: | Black |
| Environmental | |
| Ambient temperature: | -20 °C to 40 °C / -5 °F to 105 °F |
| Humidity | 30 % to 70 % RH |
| Max. altitude | 2000 m / 6562 ft |
| Electrical | |
| Power supply: | 110 - 240 VAC / 24 VDC ±10% |
| Power consumption: | < 1.4 W |
| Output circuits ratings | |
| Max switching voltage AC: | 240 V |
| Max switching voltage DC: | 30 V |
| Max switching current AC: | 10 A (per channel), 16 A (total), 18 A (total peak) |
| Max switching current DC: | 10 A |
| Sensors, meters | |
| Temperature sensor: | Yes |
| Voltmeter (AC) | Yes |
| Ammeter (AC) | Yes |
| Radio | |
| RF band: | 2400 - 2495 MHz |
| Max. RF power: | <20 dBm |
| Wi-Fi protocol: | 802.11 b/g/n |
| Wi-Fi Range: | Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions) |
| Bluetooth Protocol: | 4.2 |
| Bluetooth Range: | Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
| MCU | |
| CPU: | ESP32 |
| Flash: | 4 MB |
| Firmware capabilities | |
| Schedules: | 20 |
| Webhooks (URL actions): | 20 with 5 URLs per hook |
| Scripting: | mJS |
| MQTT: | Yes |
| CoAP: | No |
SKU
SNSW-002P16EU
EAN
3800235265031
Categorii
Greutate
1 kg
Brand
Latime (mm)
42
Umiditate (fara condensare) (%)
30% - 70%
Dimensiuni (mm)
37x42x16 ±0.5 mm
Adancime (mm)
16
Inaltime (mm)
37
Greutate (Kg)
0, 25
Garantie
2 ANI
Livrare
Min. 3 zile in momentul confirmării plăti
Intervalul de temperatura functionare
-20 to +40°C
Culoare
Negru
Conexiune
Wi-Fi
